5 Ton Rheem 17 SEER2 R454B Inverter Heat Pump System RP17AY60AJVCA, RH2TY6024STANNJ
This 5-ton Rheem system is the largest in the matched RP17AY inverter lineup, combining the RP17AY60AJVCA condenser with the RH2TY6024STANNJ two-stage air handler for R-454B refrigerant. Built for the highest residential and light-commercial loads, the inverter compressor and two-row condenser coil deliver up to 57,000 BTU of heating at 47°F while the constant-torque ECM air handler moves high-volume airflow in an AHRI-certified 17 SEER2 system.
Is the 5 Ton System the Right Size?
A 5-ton system serves the largest homes and many light-commercial spaces, often around 2,400 to 3,000-plus square feet, but capacity this large should never be chosen on floor area alone.
Oversizing a 5-ton system on a smaller home hurts comfort and humidity control, so a Manual J load calculation is especially important here. Where the load calls for it, the inverter-driven RP17AY60AJVCA covers peak demand and still modulates down for efficient part-load operation.
Ideal for: large single-family homes, spacious multi-story layouts, and light-commercial spaces needing maximum single-phase residential capacity in one matched system.
Not sure you need a full 5 tons? Compare the 4 Ton Rheem RP17AY48AJVCA Heat Pump System for a somewhat lower load.
Recommended sizing ranges are general guidelines only. Actual system requirements depend on insulation, climate, ductwork, window load, and air-sealing. Request free sizing assistance, contact Budget Heating, or call 813-885-7999.
What's Included
| Outdoor Condenser | RP17AY60AJVCA – 5 Ton Inverter-Driven Heat Pump |
|---|---|
| Indoor Air Handler | RH2TY6024STANNJ – 5 Ton Two-Stage Constant-Torque ECM |
| System Efficiency | 17 SEER2 (AHRI-certified matched system) |
| Nominal Capacity | 5 Tons (60,000 BTU class) |
| Heating Output | Up to 57,000 BTU/h @ 47°F / up to 9.5 HSPF2 |
| Refrigerant | R-454B (A2L, low GWP) |
| Electric Heat Kit | Field-installed (5/8/10 kW) – sold separately |
The RH2TY6024STANNJ multi-position air handler uses a wide 24.5-inch cabinet to handle 5-ton airflow, installs in upflow, downflow, or horizontal orientation, and is built for R-454B with a factory A2L refrigerant-detection location. The outdoor unit uses a two-row condenser coil and ships with a bi-flow liquid-line filter drier and the integrated PlusOne Refrigerant Detection System.
Condenser & Air Handler Features
RP17AY60AJVCA Condenser
- Inverter-driven PlusOne variable-speed compressor for efficient part-load modulation
- Two-row 7mm copper condenser coil for high heat rejection
- Quiet as low as 57 dBA even at full 5-ton capacity
- EcoNet-capable control with PlusOne Diagnostics & Bluetooth
- 10-year conditional parts warranty with registration
RH2TY6024STANNJ Air Handler
- Two-stage constant-torque ECM motor sized for 5-ton airflow
- Wide 24.5-inch multi-position cabinet for large-capacity installs
- Built for R-454B with a factory A2L refrigerant-detection location
- Accepts field-installed electric heat kits for supplemental heat
- Non-communicating design controlled by a standard 24V thermostat
Because the RH2TY air handler is not EcoNet enabled, this system runs on a conventional 24V thermostat, and we recommend the ecobee Smart Thermostat Lite (EB-STATE7P-01). Through the Rheem algorithm, the inverter condenser delivers full variable-speed operation with the utility 1 & 2 jumpers installed, or two-stage operation without them. For full EcoNet communicating control and the Rheem EcoNet Smart Thermostat, pair the condenser with the variable-speed RH2VY6024STACNJ EcoNet air handler instead.
Specifications & Manuals
Product documentation includes condenser and air handler technical specifications, installation instructions, the R-454B charge chart, and warranty information to assist with equipment selection, installation, and service.
Frequently Asked Questions
How much heating does the 5-ton RP17AY60 system deliver?
The matched system provides up to 57,000 BTU/h of heating at 47°F, the highest output in the RP17AY line, plus optional field-installed electric heat for supplemental capacity.
What are the components of this 5-ton matched system?
It includes the RP17AY60AJVCA inverter-driven condenser with a two-row coil and the RH2TY6024STANNJ two-stage constant-torque ECM air handler.
Which thermostat works with the 5-ton RH2TY air handler?
The RH2TY6024STANNJ is non-communicating, so use a standard 24V thermostat. We recommend the ecobee Smart Thermostat Lite, model EB-STATE7P-01.
Can the 5-ton system run variable speed with a standard thermostat?
Yes. With the utility 1 and 2 jumpers installed, the Rheem algorithm allows full variable-speed operation on a conventional 24V thermostat; without them, the system runs two-stage.
What heat kit options fit the 5-ton air handler?
Field-installed electric heat kits (commonly 5, 8, or 10 kW) are available separately and selected to match your backup-heat and electrical requirements.
Is the 5-ton system suited to light-commercial use?
Yes. As the largest single-phase system in the line, it works for large homes and many light-commercial spaces when a load calculation confirms the capacity is appropriate.
