***NOT FOR HEAT PUMPS. SINGLE REFRIGERANT FLOW DIRECTION***
The Copeland EK-032S Liquid Line Filter Drier provides dependable moisture, acid, and contaminant protection for HVAC and refrigeration systems. Its compacted-bead desiccant blend is optimized for high water and acid-removal capacity, helping protect compressors, expansion devices, and other sensitive refrigeration components.
A 20-micron outlet pad captures fine solid contaminants while allowing efficient refrigerant flow. The EK-032S also features solid copper 1/4-inch ODF connections, a shock-resistant steel shell, and a corrosion-resistant epoxy powder-coated finish.
The EK Series is designed as a universal replacement for common CFC, HCFC, and HFC refrigerants, including R-12, R-134a, R-22, R-404A, R-407C, R-410A, R-500, R-502, and R-507. It is also approved for use with POE oils in Copeland compressor applications.
Key Features
- Genuine Copeland EK Series filter drier
- 1/4" ODF sweat inlet and outlet connections
- 3 cu. in. compacted-bead desiccant
- 20-micron outlet filtration
- High moisture and acid-removal capacity
- Solid copper connections
- Shock-resistant steel shell
- Corrosion-resistant epoxy powder coating
- Approved for POE oils with Copeland compressors
- 680 PSIG maximum working pressure
- UL and cUL listed
Installation Note
Install the EK-032S in the liquid line with refrigerant flowing in the direction shown by the arrow on the filter drier. Selection and installation should be completed by a qualified HVAC or refrigeration technician.
