7.2 KW heat strip for Rheem Endeavor air handlers RH1PZ, RH2TZ, RH1PY, RH2TY
RXBH-1724B07J-1, RXBH-1724B07J-B, WRX0752I
PICTURE MAY VARY FROM ACTUAL PRODUCT
RXBH-1 Series Elecric Heat Kits
REPLACES MODEL RXBH
Standard Features
- Controlled by sequencers for better temperature control
- Mutliple branch circuit capability
- Completely assembled and tested
- Built-in overcurrent protection on all units (as indicated in the electrical data)
- Control circuit arranged to readily permit staging
- Factory-installed circuit breakers available on specific models (see electrical data)
- Fuse link secondary high-temperature limit cont
- Plug-in wiring harness for ease on installation into air handler
- Rust-resistant nickel chromium heat elements
- ETL Listed
| Equipment | Features |
| RH1PZ & RH2TZ AIR HANDLERS 17, 21, 24 | RXBH-1724* 'B' = TERMINAL Block 'S' = BREAKER SINGLE POINT 'A'=BREAKER DUAL POINT 'C'=Pullout DISCONNECT |
