PICTURE MAY VARY FROM ACTUAL PRODUCT
RXBH-1 Series Elecric Heat Kits
RXBH electric heat kits are made for Rheem/Ruud/Weatherking brand air handlers. These heat kits have built-in overcurrent protection and nickel chromium heat elements.
Standard Features
- Controlled by sequencers for better temperature control
- Mutliple branch circuit capability
- Completely assembled and tested
- Built-in overcurrent protection on all units (as indicated in the electrical data)
- Control circuit arranged to readily permit staging
- Factory-installed circuit breakers available on specific models (see electrical data)
- Fuse link secondary high-temperature limit control
- Plug-in wiring harness for ease on installation into air handler
- Rust-resistant nickel chromium heat elements
- ETL Listed
| Equipment | Features |
| RH1PZ & RH2TZ AIR HANDLERS 17, 21, 24 | RXBH-1724* 'B' = TERMINAL Block 'S' = BREAKER SINGLE POINT 'A'=BREAKER DUAL POINT 'C'=Pullout DISCONNECT |
