Liquid Line Filter Drier Sporlan 1/4 inch ODF 8cu ODF Solder Connection C-082-S (F)

he Sporlan C-082-S Catch-All Liquid Line Filter Drier is designed to protect air-conditioning and refrigeration systems from moisture, acids, dirt, scale, solder particles, sludge, and other harmful contaminants circulating with the refrigerant.

Its molded porous core uses a carefully formulated blend of molecular sieve and activated alumina to provide balanced moisture and acid removal. Refrigerant passes through the core for maximum contaminant contact, while an outlet safety filter provides additional protection against loose particles reaching the expansion valve, capillary tube, or other sensitive system components.

The C-082-S features 1/4-inch ODF copper solder connections and a compact sealed steel shell suitable for new installations, field replacements, and system service. Its 650 PSIG maximum working pressure makes it appropriate for a wide range of common HVAC and refrigeration applications.

Key Features

• Sealed Catch-All liquid line filter drier
• 1/4" ODF solder inlet and outlet connections
• Removes moisture, acids, dirt, scale, solder particles, carbon, sludge, and varnish
• Molded porous core prevents refrigerant from bypassing the desiccant
• Molecular sieve provides high moisture-removal capacity
• Activated alumina helps remove acids and lubricant breakdown products
• Outlet safety filter provides added contaminant protection
• Leak-resistant welded steel shell
• Maximum working pressure of 650 PSIG
• UL listed for refrigeration and air-conditioning applications

Product Specifications

• Brand: Sporlan
• Manufacturer: Parker Hannifin
• Series: Catch-All
• Model: C-082-S
• Manufacturer Part Number: 400429
• UPC: 687472235903
• Product Type: Liquid Line Filter Drier
• Body Style: Sealed
• Application: Air Conditioning and Refrigeration
• Connection Size: 1/4" x 1/4"
• Connection Type: ODF Solder
• Nominal Core Size: 8 cu. in.
• Filter Area: 21 sq. in.
• Maximum Working Pressure: 650 PSIG
• Overall Length: Approximately 5.12"
• Body Diameter: Approximately 2.62"
• Refrigerants: R-22, R-134a, R-404A, R-407A, R-407C, R-407F, R-410A, and R-507
• Capacity: Varies according to refrigerant, operating conditions, and application

Installation Note

Install in the direction indicated by the flow arrows on the filter drier. Product selection and installation should be completed by a qualified HVAC or refrigeration professional in accordance with Sporlan application data and applicable codes.

The universal acceptance of the Catch-All? Filter-Drier is due to its unique molded porous core, consisting of a blend of highly effective desiccants. The quality features built into it assure years of service on any refrigeration system.

• MOISTURE - The Catch-All Filter-Drier removes moisture from the refrigerant by adsorbing and retaining it deep within the desiccant granules. The blend of desiccants used in the Catch-All Filter-Drier are specially formulated for exceptional water removal.
• FOREIGN MATTER - The Catch-All Filter-Drier will filter out scale, solder particles, carbon, sludge, dirt or any other foreign matter with negligible pressure drop. Fine particles that would go through an ordinary strainer are removed down to a minimum size in one pass filtration. The large filtering area of the Catch-All Filter-Drier core permits it to collect a large amount of dirt without plug up.
• ACID- The Catch-All Filter-Drier is unexcelled in acid removal ability. The hydrochloric, hydrofluoric, and various organic acids are adsorbed and held by the desiccant in a manner similar to the adsorption of moisture. Tests have demonstrated that the Catch-All Filter-Drier has superior acid removal ability when compared to competitive driers. This ability, along with its excellent ability toclean up the oil, is responsible for the excellent field performance in cleaning up severely contaminated systems.
• OIL SLUDGE AND VARNISH- Even the best refrigeration oils break down to produce varnish, sludge and organic acids. Only the Catch-All Filter-Drier is capable of removing these products of oil decomposition.
• SPECIAL APPLICATIONS- A special ?HH? core Catch-All Filter-Drier is available to remove wax which frequently causes difficulty on low temperature refrigeration systems. For cap tube systems, use the C-032-CAP or C-032-CAP-T Catch-All which hasfittings suitable for attaching to any size capillary tube.

Remember...It?s the CORE that counts!
