Mini Split 36,000 BTU Gree Livo 21 SEER2 WiFi Heat Pump Ceiling Cassette System LIV36HP230V1R32AO, CAS36HP230V1R32AH
This is the top of Gree's single zone R32 cassette line: the LIV36HP230V1R32AO Livo condenser matched to the CAS36HP230V1R32AH 360° cassette, with the GREETF06 grille included. Three tons nominal delivers 33,600 BTU/h of rated cooling and 34,000 BTU/h of heating at 47°F, with 23,400 BTU/h still on tap at 5°F and up to 1,071 CFM of airflow from a single ceiling location. Both controllers — the wireless LCD remote and the XE72-44/E wired wall unit — plus factory-installed WiFi come with the system.
Is a 36,000 BTU Ceiling Cassette System the Right Size?
Three tons from one cassette generally addresses somewhere around 1,400 to 1,700 square feet. At this capacity the customer is usually solving a problem that ductwork cannot: a converted warehouse bay, a large sanctuary or event room, a full-floor open office, a fitness studio, or a brewery taproom where running trunk lines through an exposed ceiling was never on the table. One 33-inch grille handles the whole room.
Two specifics separate this size from the 30K beyond the extra capacity. Efficiency steps down from 22.5 to 21.0 SEER2 as the cassette coil is pushed to its limit, and the electrical profile shifts — minimum circuit ampacity actually drops to 24A while maximum overcurrent protection rises to 35A. Dehumidification climbs to 7.82 pints per hour, which matters in humid Gulf Coast and Southeast installations where latent load is half the battle. Ceiling height, insulation, glazing, door traffic, and occupancy all determine the final selection.
Ideal for: Converted warehouse and industrial bays, event and banquet rooms, full-floor open offices, fitness studios and gyms, brewery taprooms, large auto service waiting areas, and light commercial spaces of roughly 1,400 to 1,700 square feet.
Need more capacity? This is the largest single zone cassette in the R32 line. For larger loads, review the 42K - 48K BTU single zone high-efficiency systems, or consider multiple cassettes on a multi-zone ductless mini split system to zone a large space independently.
Recommended room sizes are general guidelines only. Actual system requirements depend on insulation, ceiling height, window area, ambient conditions, occupancy, and internal heat loads. Request free sizing assistance, contact Budget Heating, or call 813-885-7999.
What's Included
| Outdoor Condenser | LIV36HP230V1R32AO — 36,000 BTU Livo R32 Inverter Heat Pump |
|---|---|
| Indoor Air Handler | CAS36HP230V1R32AH 360° Four-Way Ceiling Cassette |
| Decorative Grille | GREETF06 — Included with This System |
| Controls Included | Wireless LCD Remote and XE72-44/E Wired Wall Controller |
| WiFi | Factory Installed in Condenser |
| Efficiency | 21.0 SEER2 / 11.95 EER2 / 8.5 HSPF2 |
| Rated Cooling | 33,600 BTU/h at 95°F • Modulates 7,850 - 37,500 |
| Rated Heating | 34,000 BTU/h at 47°F • 27,200 at 17°F • 23,400 at 5°F |
| Operating Range | Cooling -4°F to 122°F • Heating -13°F to 75°F |
| Refrigerant | R-32 with Factory A2L Leak Detection Sensor |
| Electrical | 208-230V, Single Phase, 60 Hz • MCA 24A • MOCP 35A |
| Line Set (Liquid - Gas) | 1/4" - 5/8" Flared • Up to 131 ft • 82 ft Rise |
| Cassette Dimensions | 33-5/64" x 33-5/64" x 9-29/64" • 50.7 lbs • 665 - 1,071 CFM |
| Condenser Dimensions | 39-3/8" x 29-3/8" x 15-13/16" • 62 dB(A) |
| AHRI Certificate | 215415560 |
Because the 24K, 30K and 36K cassettes all share the 33-5/64 inch square body, the GREETF06 grille and the 5/8 inch gas line, a contractor stocking for this line only carries two grille part numbers and two ceiling cutout dimensions across all six capacities. The 36K's distinguishing numbers are on the performance side: 1,071 CFM at top speed and 7.82 pints per hour of moisture removal, both the highest in the line.
Three-Ton Livo Condenser & Cassette Features
LIV36HP230V1R32AO Livo R32 Condenser
- Inverter compressor spanning 7,850 to 37,500 BTU/h of cooling output
- 34,000 BTU/h of heating at 47°F and 23,400 BTU/h at 5°F
- Factory-installed WiFi for app control and scheduling
- Cooling operation from -4°F to 122°F ambient
- Heating operation from -13°F to 75°F ambient
- 131 foot maximum line run with 82 feet of elevation change
- MCA 24A with 35A maximum overcurrent protection
- 62 dB(A) sound level in a 39-3/8" x 29-3/8" x 15-13/16" cabinet
- Copper tube and aluminum fin coil with intelligent defrosting
- Blue-coated fins, 500-hour salt spray tested for coastal duty
CAS36HP230V1R32AH 360° Ceiling Cassette
- 665 to 1,071 CFM — the highest airflow in this cassette line
- 7.82 pints per hour of dehumidification for high latent loads
- 38 to 52 dB(A) indoor sound level
- Four-way 360° discharge covers a large room from one location
- Shallow 9-29/64" body at only 50.7 lbs net weight
- Internal condensate drain pump with Sentry float switch
- Factory-installed A2L refrigerant leak detection sensor
- Swing louver control with vertical auto-swing
- Wireless LCD remote and XE72-44/E wired controller both included
- GREETF06 decorative grille supplied with the system
Specifications & Manuals
Livo R32 literature covers the outdoor unit used at this capacity, and the cassette service manual includes the 30K - 36K sections relevant to this indoor unit, including drain pump and float switch servicing.
Frequently Asked Questions
Is the 36,000 BTU cassette system suitable for a light commercial space?
Yes, that is its most common application. Three tons from a single ceiling cassette generally covers roughly 1,400 to 1,700 square feet, which fits event rooms, converted bays, full-floor offices, and studios where installing ductwork was impractical.
Besides capacity, how does the 36K differ from the 30K system?
Efficiency steps down from 22.5 to 21.0 SEER2, airflow rises from 1,000 to 1,071 CFM, dehumidification climbs from 7.40 to 7.82 pints per hour, and the electrical profile changes — MCA drops from 27A to 24A while maximum overcurrent protection rises from 30A to 35A.
What breaker size does the LIV36HP230V1R32AO require?
Maximum overcurrent protection is 35A with a minimum circuit ampacity of 24A on 208-230V single phase 60 Hz service. Size conductors per the installation instructions and local code for your actual run length.
How much moisture can the CAS36HP230V1R32AH remove per hour?
7.82 pints per hour, the highest figure in this cassette line. That latent capacity is a meaningful advantage in humid Gulf Coast and Southeast installations where sensible cooling alone leaves a room feeling clammy.
Is this the largest single zone cassette Gree offers in the R32 line?
Yes. The 360° cassette line runs 9K, 12K, 18K, 24K, 30K and 36K, and this is the top capacity. Larger loads are typically handled with a higher-tonnage system or by dividing the space across multiple cassettes on a multi-zone condenser.
Does the 36K cassette need a larger ceiling opening than the 24K?
No. The 24K, 30K and 36K cassettes all use the 33-5/64 inch square by 9-29/64 inch deep body and the same GREETF06 grille, so the ceiling cutout and plenum requirement are identical across those three sizes.
