Kramer 1/2 HP R448A/R449A Medium-Temp Refrigeration Condensing Unit 208/230V 1PH, KFO060M4SDA

Kramer 1/2 HP R448A/R449A Medium-Temp Refrigeration Condensing Unit 208/230V 1PH, KFO060M4SDA

The Next-Gen MiniCon Kramer ½ through 6 HP condensing units are engineered with increased efficiency, more standard features, are easier to service, and have more cataloged options. Next-Gen MiniCon's are suited for use in a variety of commercial applications such as cafeterias, convenience stores, restaurants and fast food outlets while providing the versatility to excel in a full array of other applications. Made from high quality materials that increase flexibility and greatly improve efficiency for even lower long-term operating costs. The small profile product line is designed to utilize R448A or R449A refrigerant. Using Copeland scroll compressors, the Next-Gen condensers are rated for operation in ambient air temperatures up to 110° F.

Standard Features
• Factory Nitrogen Charge
• Efficient Scroll compressor
• All-weather - Galvanized steel painted housing
• Generously sized high efficiency condenser, enhanced copper tubes/aluminum fins
• Integral Liquid Subcooling Circuit provides subcooled liquid to the expansion device
• Base mounted shut-off valves placed external to cabinet for easy access
• Liquid line kit with filter/drier and sight glass with moisture indicator
• Suction line piping
• Larger electrical panel with hinged/removable door
• Color-coded point-to-point wiring
• Crankcase heater
• Refrigerant receiver with isolation valve and pressure relief plug
• PSC condenser fan motor(s) with EC motor option
• Encapsulated high pressure (auto reset) and low pressure (auto reset) controls (adjustable low pressure control is standard on low temperature models)
• Electronic defrost timer with defrost contactor/relay on low temperature models (2 evaps. maximum)
• Electronic air defrost timer (Medium temperature models only)
• UL and cUL listed for indoor or outdoor use
