EcoTemp 3 Ton Wall Mount Apartment Type Air Handler FMA4X3600AL
The EcoTemp model FMA4X3600AL 3 ton air handler is designed to be installed in a multi-family apartment style housing environment (apartments, condominiums, town homes, etc...). The FMA4X wall mount air handler is a wall hung unit that fits in a closet above a water heater in most applications and has a louvered door or a return air grill through the wall to allow front or bottom return airflow. This unit CAN be converted to bottom return! Must be installed vertically in an up-flow application ONLY. Unit fits between standard stud spacing.
EcoTemp apartment style central air conditioning systems can be registered in a commercial environment to the original owner and receive a 10 year all parts warranty! This is the best warranty in the industry for apartment style systems, most other brands are 5 years only!
Certified to achieve a 2% or less leak rate at 1" water column! Includes primary and secondary drain fittings and multiple electrical entry locations and time delay relay for ease of installation. R410A and R22 refrigerant compatible!
· 1−1/2, 2, 2−1/2, and 3 Tons
· Upflow application only
· Accessory field−installed electric heat kits available in 5,
7.5, or 10 kW
· 208/230−1−60 supply voltage
· Front return convertible to bottom return
· Cabinet exterior is galvanized sheet metal
· Sealed to meet 2% cabinet leakage when tested at 1.0 in.
w.c. of static pressure
· Fully insulated for conditioned space (not to be installed in
· Copper tube, aluminum fin coil
· For use with R−410A refrigerant or R−22 with accessory
· R−410A refrigerant TXV standard or for use with R−22
with accessory R−22 TXV
· ECM motor on all FMA4X
· Motor suspended on rubber grommets for quieter
· Fresh air intake holes (capped from factory)
EASY TO INSTALL AND SERVICE
· Units fits between standard stud spacing
· All service access is located in the front
· Primary and secondary drain connections exit from the
· No return−air ductwork required in specific applications
· Wall hanging brackets included with the unit
· 5 year parts limited warranty
