Price Includes $1,500 Core Fee. Refunded If Core Returned.
From data centers to supermarkets, customers count on Carlyle to deliver quiet, reliable, efficient performance across a wide range of applications.
These 06D compressors are re-manufactured by one of the U.S. top-leading builders in the industry.
Built and tested to match strict OEM specifications, these compressors are practically brand new without the brand new sticker shock!
Core charge deposit is built into initial cost and refunded back to customer once old compressor is returned to re-manufacturer.
Return shipping for this is an add on option below which can be waived if customer would like to keep defective part.
Please understand, in doing so, any core charge will than be forfeited and not credited after sale.
TwoYear Warranty is standard under normal operation (more details below).
From data centers to supermarkets, customers count on Carlyle to deliver quiet, reliable, efficient performance across a wide range of applications.
These 06D compressors are re-manufactured by one of the U.S. top-leading builders in the industry.
Built and tested to match strict OEM specifications, these compressors are practically brand new without the brand new sticker shock!
Core charge deposit is built into initial cost and refunded back to customer once old compressor is returned to re-manufacturer.
Return shipping for this is an add on option below which can be waived if customer would like to keep defective part.
Please understand, in doing so, any core charge will than be forfeited and not credited after sale.
TwoYear Warranty is standard under normal operation (more details below).
Features
- - High-flow, automatically reversible oil pump provides positive-displacement oil lubrication.
- - Crankcase venting system equalizes pressure during startup and assures oil return to sump.
- - Oversize sump holds extra oil in crankcase to prevent levels dropping below safe lubrication range during flooded starts.
- - Contoured pistons lower cylinder clearances to increase compressor capacity and efficiency.
- - High-efficiency valves provide increased refrigerant flow and lower pressure drops.
- - Electronic oil-pressure switch.
06D/E APPLICATION GUIDEPERFORMANCE & PHYSICAL DATA
| Size | Capacity Low Temp. (tons) | Capacity Medium Temp. (tons) | Capacity High Temp. (tons) | Length / Depth (in) | Width (in) | Height (in) | Operating Weight (lb) |
|---|---|---|---|---|---|---|---|
| 8 | 0.62 | 1.74 | 3.04 | 19 | 10 | 15 | 160 |
| 13 | 0.98 | 2.66 | 4.74 | 22 | 15 | 15 | 235 |
| 16 | 1.23 | 3.4 | 5.9 | 22 | 15 | 15 | 235 |
| 18 | 1.46 | 3.95 | 6.91 | 24 | 15 | 17 | 250 |
| 20 | 1.73 | 4.8 | 7.95 | 24 | 15 | 17 | 260 |
| 24 | 1.83 | 5.48 | 8.81 | 24 | 16 | 15 | 310 |
| 28 | 2.19 | 6.19 | 10.64 | 24 | 18 | 16 | 315 |
| 37 | 2.97 | 8.6 | 14.6 | 24 | 18 | 16 | 325 |
| 41 | 3.24 | 9.1 | N/A | 24 | 18 | 16 | 325 |
Two Year Warranty Details:
Our re-manufactured compressors are guaranteed for a period of
Our re-manufactured compressors are guaranteed for a period of
